Risk Factors

It is not always known what causes the lack of blood supply, but doctors have identified a number of risk factors that make someone more likely to develop osteonecrosis.

• Injury. A knee injury — such as a stress fracture or dislocation—combined with some type of trauma to the knee, can damage blood vessels and reduce blood flow to the affected bone.
• Oral corticosteroid medications. Many diseases, such as asthma and rheumatoid arthritis, are treated with oral steroid medications. Although it is not known exactly why these medications can lead to osteonecrosis, research shows that there is a connection between the disease and long-term steroid use. Steroid-induced osteonecrosis frequently affects multiple joints in the body.
• Medical conditions. Osteonecrosis of the knee is associated with medical conditions, such as obesity, sickle cell anemia, and lupus. Osteonecrosis is also commonly seen in patients with HIV due to the medications used for HIV treatment.
• Transplants. Organ transplantation, especially kidney transplant, is associated with osteonecrosis.
• Excessive alcohol use. Overconsumption of alcohol over time can cause fatty deposits to form in the blood vessels as well as elevated cortisone levels, resulting in a decreased blood supply to the bone.

Regardless of the cause, if osteonecrosis is not identified and treated early, it can develop into severe osteoarthritis.

Physical Examination

Your doctor will talk with you about your general health and medical history and ask you to describe your symptoms. They will then perform a careful examination of your knee, looking for:

• Joint swelling, warmth, or redness
• Tenderness
• Range of passive (assisted) and active (self-directed) motion
• Instability of the joint
• Pain when weight is placed on the knee
• Any signs of injury to the muscles, tendons, and ligaments surrounding the knee

During the exam, your doctor will look for areas of tenderness about your knee.

Reproduced from JF Sarwark, ed: Essentials of Musculoskeletal Care, ed 4. Rosemont, IL, American Academy of Orthopaedic Surgeons, 2010.

Imaging tests will help your doctor confirm the diagnosis.

Imaging Tests

X-rays. X-rays provide images of dense structures, such as bone. Your doctor may order X-rays to look for changes that occur in bone in the later stages of osteonecrosis. In the early stages of the disease, X-rays usually appear normal.

X-ray shows osteonecrosis at the lower end of the femur (thighbone) in the medial femoral condyle.

Reproduced from JF Sarwark, ed: Essentials of Musculoskeletal Care, ed 4. Rosemont, IL, American Academy of Orthopaedic Surgeons, 2010

As osteonecrosis progresses, narrowing of the joint space can occur due to loss of articular cartilage.

Reproduced from Woehnl A, Naziri Q, Costa C, Johnson AJ, Mont MA: Osteonecrosis of the knee. Orthopaedic Knowledge Online Journal 2012; 10(5). Accessed May 2016.

Magnetic resonance imaging (MRI) scans. Early changes in the bone that may not show up on an X-ray can be detected on an MRI.

• MRI scans are used to evaluate how much of the bone has been affected by the disease.
• An MRI scan may also show early osteonecrosis that has yet to cause symptoms — for example osteonecrosis that may be developing in the opposite knee joint.

This MRI scan shows osteonecrosis in the medial femoral condyle. An MRI is often used to detect early symptoms of the disease.

Reproduced from JF Sarwark, ed: Essentials of Musculoskeletal Care, ed 4. Rosemont, IL, American Academy of Orthopaedic Surgeons, 2010.

Bone scan. In some cases, the doctor may order a bone scan. During this test, a very small amount of radioactive dye is injected into your vein. Osteonecrosis may cause an increased uptake of the radioactive material in the bone due to bone activity.

Nonsurgical Treatment

In the early stages of osteonecrosis, treatment is nonsurgical. If the affected area of the knee is small, nonsurgical treatment may be all that is needed.

Nonsurgical treatment may include:

• Medications
  • Nonsteroidal anti-inflammatory drugs (NSAIDs), such as ibuprofen and naproxen, can help reduce pain and swelling in your knee.
  • Your doctor may also talk to you about bisphosphonates for treatment, especially if you are at a younger age when you are diagnosed.
• Reduced weightbearing. For some patients, removing weight from the affected knee can slow the damage caused by osteonecrosis and allow healing. Your doctor may recommend using crutches for a period of time to take weight off your knee. In some cases, wearing an "unloader" brace can help relieve pressure on the joint surface by shifting weight away from the affected portion of the knee.
• Exercise. Your doctor or a physical therapist may provide you with an exercise program designed to help strengthen your thigh muscles and maintain range of motion in the affected joint. In some cases, water exercise may be recommended to avoid stress on your knee joint.
• Activity modification. Your doctor may recommend that you avoid certain activities that bring on painful symptoms.

Surgical Treatment

If a large portion of the bone surface is affected, or if your pain does not improve with nonsurgical treatment, your doctor may recommend surgery. There are several different procedures used to treat osteonecrosis of the knee.

Arthroscopic debridement and microfracture. In debridement (cleansing), your doctor uses a small camera and miniature surgical instruments to remove loose bits of bone or damaged cartilage from inside the joint space. For small lesions, the surgeon may also drill multiple holes, or microfractures, in the underlying bone to help promote blood flow and induce a healing reaction

Core decompression. This procedure involves drilling one larger hole or several smaller holes into the bone to relieve pressure on the bone surface and create channels for new blood vessels to nourish the affected areas of the knee.

When osteonecrosis of the knee is diagnosed early, core decompression is often successful in preventing collapse of the bone and the development of arthritis.

Core decompression on a patient with early stage osteonecrosis.

Reproduced from Woehnl A, Naziri Q, Costa C, Johnson AJ, Mont MA: Osteonecrosis of the knee. Orthopaedic Knowledge Online Journal 2012; 10(5). Accessed May 2016.

Osteochondral (bone and cartilage) grafting. Core decompression is often combined with bone and cartilage grafting to help regenerate healthy bone and support cartilage at the knee joint. A bone graft is healthy bone tissue that is transplanted to an area of the body where it is needed. The tissue may be taken from a donor (allograft) or from another bone in your body (autograft).

There are also several synthetic bone grafts available today.

Autologous chondrocyte implantation (ACI). This is a two-stage procedure. In the first stage, your doctor performs an arthroscopic procedure to remove a small number of cartilage-producing cells (chondrocytes) from your knee. These chondrocytes are sent to a lab where they are cultured (multiplied) for up to 6 weeks to obtain more cells.

In the second stage, your doctor performs another procedure to implant the chondrocytes into the area of your knee with cartilage loss. The cells then grow in the joint, replacing the damaged cartilage with healthy cartilage.

Osteotomy. In an osteotomy, either the tibia (shinbone) or femur (thighbone) is cut and then reshaped. The surgeon will either remove a portion or bone or insert a wedge of bone graft or synthetic bone to help shift weight off the damaged area of your knee. Shifting your weight off the damaged side of the joint will help relieve pain and improve function.

Total knee replacement or unicompartmental (partial) knee replacement. If the disease has advanced to the point where the bone has already collapsed, you may need surgery to replace the damaged parts of your knee. In knee replacement, your doctor removes the damaged bone and cartilage, and then positions new metal or plastic joint surfaces to restore the function of your knee.
